Buoys, floating ball fill two components low pressure polyurethane foam machine is the liquid polyols and isocyanates two components of the raw materials respectively stored in two material storage tank, by two rotary precision gear metering pump to the mixed system, the pressure under the action of mixing head open, two components were injected into the small in the mixing chamber, a mixing blade high speed stirring and mixing effect, make the material liquid evenly, to form the required product.
Equipment application: this model is suitable for the production of buoy, float ball polyurethane filling and other products.
Equipment technical parameters:
unit type
LXPU-RY2-240
LXPU-RY2-350
LXPU-RY2-500
LXPU-RY2-800
Flow rate (g/s)
60-240
80-350
100-500
160-800
Buoys, floating ball fill two components high-pressure polyurethane foam machine is the liquid polyols and isocyanates two components of the raw materials respectively stored in two material storage tank, by two rotary axial plunger metering pump (radial) sent to the mixed system, under the action of hydraulic mixing head open, two components at high pressure and velocity were injected into the small mixing chamber, the high speed collision and mixing effect, make the material liquid evenly, to form the required product.
Equipment application: this model is suitable for the production of buoy, float ball polyurethane filling and other products.
