Bicycle air-free solid tire production can choose bicycle air-free solid tire two-component low-pressure foam machine, bicycle air-free solid tire disc line, the machine picture is as follows:
Two-component low-pressure foam machine of bicycle air-free solid tire is a new product independently developed by lingxin company.
Equipment application: this model is suitable for producing bicycle free inflatable solid tire and other products.
Technical Parameter
Item/model
total spit out quantity
（g/s）
total power（kw）
Head stirring speed（r/min）
mix proportion
Overall dimensions
(length X width X height)
weight（kg）
soft
bubble
RY2-500
100-500g
15
5200
100：50-150
2200*1400*2300
1000
RY2-800
160-800g
15
5200
100：50-150
2200*1400*2300
1000
The disc line of bicycle gas-free solid tire is used in the foaming production of various polyurethane products. The equipment operates at a constant speed, and the running speed can be adjusted to the production beat. The disk is equipped with a power supply and air source conveying system. It forms a complete foaming production line with mold temperature machine.
Equipment application: this production line is suitable for the production of bicycle gas-free solid tires and other products.
Equipment features:
1) the equipment is simple and easy to use.
2) labor saving.
3) high yield.
4) the mold is heated by water in the mold temperature machine and heated evenly.
