Bodybuilding equipment pillows and cushions can be made of two-component polyurethane low-pressure foaming machine, two-component polyurethane high-pressure foaming machine or polyurethane disc line. The machine pictures are as follows:
The two-component low-pressure foaming machine for the backrest and cushion of fitness equipment is a new product independently developed by linxin company.
Equipment application: this model is suitable for the production of fitness equipment pillow, cushion and other products.
Equipment technical parameters
Item/model
Always spit out quantity
（g/s）
total power（kw）
Head stirring speed（r/min）
mix proportion
Overall dimensions
(length X width X height)
weight（kg）
soft
bubble
RR2-700
125-700g
11
5200
100：50-150
2200*1400*2300
1000
Fitness equipment back cushion, cushion 2 components of high pressure foaming machine is to polyols and isocyanates two components of the liquid raw materials stored in two material storage tank respectively, with two rotating axial plunger metering pump (radial) sent to the mixed system, under the action of hydraulic mixing head open, two components was injected into the small mixing chamber with a high speed, high speed collision and mixing effect, make the material liquid evenly, mixing effect is good, no clean, stable performance, easy operation, achieve the goal of high production efficiency and environmental protection.
Equipment application: this model is suitable for the production of fitness equipment pillow, cushion and other products.
Equipment technical parameters:
Item/model
H2-L25
Spit out quantity（g/s）
90-400g/s
A tank capacity（L）
250/500
B tank capacity（L）
250/500
injection pressure（mpa）
5-15
inject time（S）
0.5-99.99
total power（kw）
26
weight（kg）
1800
The production line of bodybuilding pillow and cushion is used for the continuous foaming production of all kinds of car seats. The equipment operates at a constant speed, and the running speed can be adjusted to the production beat. The disk is equipped with a power supply and air source conveying system. It forms a complete foaming production line with mould frame and mould temperature machine.
Equipment application: this production line is suitable for the production of fitness equipment pillow, cushion and other products.
Equipment features:
Continuous cycle operation, simple operation, smooth transmission, high production efficiency.
